GOODWE
RESIDENTIAL ONGRID SOLUTION- GW5000-DNS-40
Barcode:
57325574
Key Features
Rated Output: 5kW
Type: Single-Phase On-Grid Solar Inverter
2 MPPTs: Flexible solar-panel configuration
Max. DC Input: 7.5kW
Max. DC Voltage: 600V
Max. Input Current: 16A per MPPT
Max. Efficiency: Up to 98.1%
DC Oversizing: Up to 150%
Fanless Cooling: Quiet natural-convection design
AFCI Protection: Enhanced arc-fault protection
IP66 Protection: Suitable for outdoor installation
Smart Monitoring: Wi-Fi/LAN/4G communication options
Residential Use: Ideal for rooftop solar and net-metering systems.
Share:
Product Description:
GoodWe GW5000-DNS-40 Residential On-Grid Solar Solution
Product Description
The GoodWe GW5000-DNS-40 Residential On-Grid Solar Solution is a reliable 5kW single-phase solar inverter solution designed for residential grid-connected solar installations. It converts DC electricity generated by solar panels into usable AC electricity, helping households utilize clean solar energy for their daily power requirements.
Designed for rooftop solar applications, the GW5000-DNS-40 offers flexible PV system compatibility, efficient energy conversion, and a practical design for residential installations. It is suitable for homes and small properties looking to generate renewable electricity while remaining connected to the utility grid.
Key Features
5kW single-phase on-grid solar inverter
Designed for residential solar installations
Efficient DC-to-AC power conversion
Dual MPPT design
Supports multiple PV strings
Wide PV voltage operating range
Compact and practical design
Suitable for grid-connected rooftop systems
Product Highlights
5kW Power Capacity: Suitable for residential solar systems with higher energy requirements.
Dual MPPT: Helps optimize solar energy harvesting from different PV string configurations.
Single-Phase Operation: Designed for compatible residential electrical systems.
Efficient Conversion: Converts solar-generated DC power into usable AC electricity.
Flexible PV Configuration: Supports multiple solar panel string arrangements.
On-Grid Operation: Designed to work alongside the utility grid.
Residential Ready: Suitable for rooftop solar and net-metering applications.
Ideal For
Residential rooftop solar systems
Medium-sized homes
Grid-connected PV installations
Net-metering systems
Small offices and commercial spaces
Renewable energy projects
product included:
Specifications:
Specification | Details |
|---|---|
Model | GW5000-DNS-40 |
Type | Residential On-Grid Solar Inverter |
Phase | Single Phase |
Rated Output Power | 5,000W / 5kW |
Max. DC Input Power | 7,500W |
Max. DC Input Voltage | 600V |
MPPT Operating Range | 40–560V |
Start-up Voltage | 50V |
Max. Input Current | 16A per MPPT |
Max. Short-Circuit Current | 23A per MPPT |
MPPT Trackers | 2 |
Strings per MPPT | 1 |
Nominal AC Voltage | 220/230/240V |
Grid Frequency | 50/60Hz |
Max. Output Current | 22.8A |
Max. Efficiency | Up to 97.9% |
Weight | 9.2 kg |
Power Factor | ~1, adjustable 0.8 leading to 0.8 lagging |
THD | <3% |
Cooling | Natural Convection |
Communication | Wi-Fi, RS485, LAN/4G options |
Protection Rating | IP66 |
Operating Temperature | -25°C to +60°C |
Max. Operating Altitude | 4,000m |
DC Connector | MC4 |
AC Connector | Plug-and-play |
Application | Residential rooftop & net-metering solar |
