Hithium
HeroEE 16 Battery
Barcode:
31714675
Key Features
16.0768kWh Large Battery Capacity
51.2V Nominal Voltage
LiFePO₄ Battery Technology
314Ah Battery Capacity
Up to 11,000 Battery Cycles
90% Depth of Discharge (DoD)
100A Recommended Charge/Discharge Current
200A Maximum Charge/Discharge Current
Smart Battery Management System (BMS)
Built-in LCD Touchscreen
CAN / RS485 / RS232 Communication
Optional Wi-Fi & Bluetooth
Expandable up to 256kWh
Up to 16 Batteries in Parallel
Natural Cooling — Fanless Design
IP30 Protection
Four Integrated Wheels
Compatible with Multiple Inverter Brands
Indoor, Stand-Alone Installation
CE, CB, UN38.3 & IEC62619 Certified
Share:
Product Description:
HiTHIUM HeroEE 16 Battery Energy Storage System
Product Description
The HiTHIUM HeroEE 16 Battery is a high-capacity energy storage solution designed to provide reliable power storage for residential and energy backup applications. It allows electricity generated from compatible solar systems to be stored and used when needed, helping households improve energy utilization and power availability.
Designed for integration with compatible HeroEE energy storage systems, the battery provides a flexible solution for storing renewable energy. Stored power can be used during periods of low solar generation or grid interruptions, supporting essential household loads and improving energy independence.
The HeroEE 16 Battery is a practical choice for users looking for larger energy storage capacity, solar self-consumption, and backup power support.
Key Features
High-Capacity Battery Energy Storage
Residential Energy Storage Solution
Solar Energy Storage Support
Backup Power Capability
Efficient Energy Management
Scalable Energy Storage
Compatible HeroEE System Integration
Reliable Power Storage
Product Highlights
High-capacity energy storage
Stores excess solar energy for later use
Supports backup power applications
Helps improve solar self-consumption
Suitable for residential energy systems
Flexible energy storage configuration
Designed for compatible HeroEE systems
Ideal For
Residential solar PV systems
Home battery energy storage
Solar + battery installations
Backup power systems
Renewable energy storage
Homes with higher energy storage requirements
product included:
Specifications:
Specification | Details |
|---|---|
Model | HeroEE 16 |
Product Type | Low-Voltage Residential ESS Battery |
Battery Chemistry | LiFePO₄ (LFP) |
Battery Capacity | 16,076.8Wh / 16.0768kWh |
Cell Capacity | 314Ah |
Rated Voltage | 51.2V DC |
Operating Voltage Range | 43.2–58.4V DC |
Recommended Charge/Discharge Current | 100A |
Maximum Charge/Discharge Current | 200A |
Depth of Discharge (DoD) | 90% |
Battery Cycle Life | Up to 11,000 cycles |
Charge Mode | CC-CV |
Communication Ports | CAN / RS485 / RS232 |
Display | LCD Touchscreen |
Maximum Parallel Units | 16 batteries |
Maximum Expandable Capacity | Up to 256kWh |
Cooling | Natural Convection |
Ingress Protection | IP30 |
Charging Temperature | 0°C to 40°C |
Discharging Temperature | -20°C to 40°C |
Storage Temperature | -20°C to 60°C |
Humidity | 10%–90% RH |
Installation | Indoor, Stand-Alone |
Dimensions | 540.6 × 240 × 781.2 mm |
Net Weight | Approx. 110 kg |
Certifications | CE, CB, UN38.3, IEC 62619 |
Contact for more details
Call now: 01711305205
