GOODWE
C&I ONGRID SOLUTION- GW50K-SDT-C30
Barcode:
37913835
Key Features
50kW rated AC output
Three-phase on-grid inverter
4 MPPTs / 8 PV strings
Up to 98.7% efficiency
1100V maximum DC input voltage
40A maximum input current per MPPT
Up to 180% PV oversizing supported by the SDT G3 series
Type II DC & AC surge protection
Optional AFCI 3.0
IP66 protection
Smart fan cooling
Noise level <50 dB
RS485, Wi-Fi/LAN/Bluetooth communication options
Suitable for commercial & industrial solar projects
Share:
Product Description:
GoodWe GW50K-SDT-C30 C&I On-Grid Solar Solution
Product Description
The GoodWe GW50K-SDT-C30 is a 50kW three-phase on-grid solar solution designed for commercial and industrial (C&I) applications. It efficiently converts solar energy generated by PV panels into usable AC electricity while operating in synchronization with the electrical grid.
With its high-capacity design, the solution is suitable for businesses and facilities with significant energy requirements. It helps maximize solar energy utilization, support efficient power generation, and reduce dependence on conventional grid electricity.
Key Features
50kW On-Grid Solar Solution
Three-Phase Grid Connection
Commercial & Industrial Applications
Efficient DC-to-AC Conversion
Multiple MPPT Support
Flexible PV System Configuration
Grid-Connected Operation
High-Capacity Solar Solution
Product Highlights
50kW power capacity
Three-phase solar energy system
Efficient solar-to-electricity conversion
On-grid operation
Multiple MPPT support
Suitable for large PV installations
Designed for C&I solar projects
Practical solution for renewable energy generation
Ideal For
Commercial buildings
Industrial facilities
Factories and warehouses
Large offices and business premises
Large rooftop solar installations
Commercial & industrial PV projects
product included:
Specifications:
Specification | GW50K-SDT-C30 |
|---|---|
Product Type | C&I On-Grid Solar Inverter |
Rated Output Power | 50,000 W / 50 kW |
Max. Input Voltage | 1100 V DC |
MPPT Operating Range | 140–1000 V |
Start-up Voltage | 160 V |
Nominal Input Voltage | 600 V |
Max. Input Current / MPPT | 40 A |
Max. Short-Circuit Current / MPPT | 52 A |
Number of MPPTs | 4 |
Strings per MPPT | 2 |
Total PV Strings | 8 |
Nominal AC Voltage | 220/380V, 230/400V, 240/415V |
AC System | 3L/N/PE or 3L/PE |
Grid Frequency | 50/60 Hz |
Max. Output Current | 75.7 A @ 380V |
Power Factor | Approximately 1, adjustable from 0.8 leading to 0.8 lagging |
Max. THD | <3% |
Maximum Efficiency | 98.7% |
European Efficiency | 98.0% |
DC Surge Protection | Type II |
AC Surge Protection | Type II |
AFCI | Optional |
Protection Rating | IP66 |
Operating Temperature | -30°C to +60°C |
Maximum Altitude | 4000 m |
Cooling | Smart Fan Cooling |
Communication | RS485, Wi-Fi + LAN + Bluetooth |
Communication Protocol | Modbus-RTU / Modbus-TCP |
Dimensions | 646 × 484 × 230 mm |
Weight | 33 kg |
Noise | <50 dB |
Topology | Non-isolated |
